Integration of Penta-Combo LWD Measurements for Petrophysical and Geomechanical Feasibility

Abstract

Advanced levels of depletion cause unexpected reduced pore pressures and thus reduced reservoir fracture gradients, presenting considerable drilling challenges in the Burgan Field in Kuwait. This can lead to matrix damage due to mud losses and result in borehole collapse due to the relative increase of effective stress concentration in the vicinity of the borehole. The area of the study showed high levels of non-productive time (NPT) as well as increased costs due to the drilling of unplanned sidetracks in highly deviated wells. LWD Penta-combo measurements including azimuthal sonic and formation pressure have been utilized to model fracture gradient and borehole collapse gradient in real-time, and proved effective at reducing risks and rig time by allowing proactive management of these challenges.

Borehole collapse in offset wells was analyzed to predict and simulate the wellbore stability of a planned well via a pre-drill geomechanics model prior to drilling the well. The well was planned with a high deviation of 56° and oil based mud. The salinity of the water phase was recognized as an essential factor in assessing wellbore stability risk with respect to shale-dependent time failure.

The integration of real-time LWD sonic and density data with formation pressure testing data in the geomechanics model for the first time in the 12 ¼-in. section showed excellent correlation and confirmed different levels of depletion in the reservoir. Uncertainty in the modeled fracture gradient was significantly reduced and effectively eliminated with the inclusion of real-time formation pore pressure testing data. This successful combination of modeled pore-pressure curves from the real-time LWD sonic data with the real-time formation pressure test data acquired while drilling in the same run is a first in Kuwait. A total of 15 pressure points were sampled in real time while drilling, allowing for proactive mud window optimization and borehole stability geomechanical analysis.

This real-time wellbore stability technique based on advanced LWD azimuthal acoustic technology in conjunction with real-time formation pressure testing while drilling has been developed with a unique process and workflow allowing the operator to drill the well with no significant wellbore stability issues and with the optimized shape of the borehole for a safe casing run. In addition, NPT was reduced to 0 hours and overall days per well were reduced significantly.
